TH-6F0102 Industrial Media Converter 1xGigabit SFP, 2×10/100Base-T

Model Number: TH-6F0102

Brand: Todahika

  • Complies with the IEEE 802.3, IEEE 802.3u
  • Supports packet size of up to 10K bytes

Product Detail


Ordering Information



Product Tags

Product Description

Introducing the TH-6F0102 Industrial Ethernet Media Converter, a cutting-edge solution designed to provide reliable power to small and medium businesses (SMBs) deploying Power over Ethernet (PoE) networks. This industrial-grade converter features a fanless, energy-efficient design that ensures optimal performance while reducing power consumption.

The TH-6F0102 is compact in size, convenient and easy to maintain, ensuring hassle-free installation. The media converters are designed to withstand harsh operating conditions with a temperature range of -40°C to +75°C. Whether it is a control cabinet in a transportation system, a factory floor, an outdoor location, or other extreme temperature environments, the converter guarantees continuous and reliable operation.


  • Previous:
  • Next:

  • ● Complies with the IEEE 802.3, IEEE 802.3u.

    ● Auto-MDI/MDI-X detection and negotiation in half/full-duplex modes for 10/100Base-TX RJ-45 port.

    ● Features Store-and-Forward mode with wire-speed filtering and forwarding rates.

    ● Supports packet size of up to 10K bytes.

    ● Robust IP40 protection, fan-less design, high/low temperature resistance -40℃~ +75℃.

    ● DC12V-58V input.

    ● CSMA/CD protocol.

    ● Automatic source address learning and aging.

    P/N Description

    Unmanaged Industrial Media Converter

    1x1000Mbps SFP Port, 2×10/100/1000M RJ45 Port


    Unmanaged Industrial PoE Media Converter

    1x1000Mbps SFP Port, 2×10/100/1000M RJ45 Port PoE

    TH-6F0102 Industrial Media
